9028
Simply A SMARTER INVESTMENT

Engineered to bring you the innovation you deserve with the simplicity you require, the Markem-Imaje 9028 will facilitate daily operations and save you time!

Thanks to its innovative, all inclusive M6’ ink circuit, your production will never stop for 2 full years*. Easy to change, the M6’ can be clicked-in and clicked-out in less than 6 minutes and with no specialized tools. Also, its new innovative cartridge system and associated ink offer (MEK-free and permanent ink) make set-up automatic and clean, optimizing your operators’ time and your overall production uptime.

Your benefits

• Up to 4 lines of print
• Print speed up to 4.4 m/s
• Creation of logos directly on the operator/machine interface
• Jet Speed Control guarantees marking quality
• Automatic selection of fonts, depending on print speed and printhead/object distance

___________________________________________________

Operations

▶ Message library (up to 100 messages)
▶ International operator/machine interface (choice of 31 languages)
▶ L arge wysiwyg backlit blue screen
▶ Integrated help for navigation and diagnostics
▶ C reation of logos directly on the operator/machine interface
▶ USB port
▶ M 6’ ink circuit
▶ Jet Speed Control guarantees marking quality
▶ Automatic selection of fonts, depending on
print speed and printhead/object distance
▶ Possibility to choose ink types: quick-drying MEK-free
and MEK , alcohol-based, color changing for sterilization process
▶ 2 sealed intelligent cartridges, 0.8 liter each
▶ Quick connect/disconnect of accessories (photocell, encoder, alarm)
▶ RS-232 connectivity

Other

Characteristics

▶ Weight: 18.5 kg
▶ 2-meter flexible umbilical cable
▶ Stainless steel cabinet
▶ Dust/humidity protection rating: IP55 rating
▶ No plant air required
▶ Operating temperature range: 0° to 40°C, depending on ink used
▶ Humidity: 10% to 90% non-condensing
▶ Electrical power supply:100-120 V or 200-240 V with automatic
switching; frequency 50/60 Hz; power 34 W

________________________________________________________________________

Options

▶ Ethernet connectivity
▶ Printhead pressurization kit (plant air required)
▶ Autonomous pressurization kit (no plant air required)
▶ 3-meter umbilical


________________________________________________________________

Accessories

▶ Printer supports: stands (stainless steel or aluminum),
table or wall mounting bracket
▶ Stainless steel printhead cover
▶ Photocell
▶ Encoder
▶ Alarm beacon (24 V)
